Side of HF.9129 - Hydraulikfilter Top of HF.9129 - Hydraulikfilter Bottom of HF.9129 - Hydraulikfilter
Hydraulikfilter

HF.9129

46,00 € Alle Preise sind ohne Mehrwertsteuer.
Oxfil code: HF.9129 Lager: 5 Delivery time: Immediately available

In den Korb

  1. Properties
  2. Anwendung
  3. Vergleichsnummern
  4. Ähnliche Produkte
Element Collapse pressure (COL-P)
20 bar
Filtration Media (FILT-MED)
Inorganic Microfibers 12 µm
Flow direction (FLOW-DIR)
Out-In
Total Height (H-TOTAL)
196 mm
Seal (SEAL)
NBR
Bypass Valve Opening Pressure (UGV)
3 bar
Product Net Weight (WEIGHT)
0.74 Kg
Largest Inner Diameter (Ø IN-MAX)
48.5 mm
Smallest Inner Diameter (Ø IN-MIN)
46 mm
Outer Diameter (Ø OUT)
95 mm
Stat. HS-Code
84149000
