Side of Stauff LL045B10B - Hydraulic Filter

Side of Stauff LL045B10B - Hydraulic Filter

Только для справки

Hydraulic Filter

Stauff LL045B10B

111,00 € Все цены указаны без НДС.

Brand reference: Stauff Brand code: LL045B10B Oxfil code: HF.7726 Склад: По запросу
В наличии?

Поместить в корзину

Properties
Применение
Перекрестные ссылки
Связанные продукты

Property image

Element Collapse pressure (COL-P)

10 bar

Filtration Media (FILT-MED)

Wire Mesh 13 µm

Flow direction (FLOW-DIR)

Out-In

Height-1 (H-1)

2 mm

Total Height (H-TOTAL)

162 mm

Seal (SEAL)

NBR

Largest Inner Diameter (Ø IN-MAX)

71 mm

Smallest Inner Diameter (Ø IN-MIN)

65 mm

Outer Diameter (Ø OUT)

110 mm

Largest Outer Diameter (Ø OUT-MAX)

115 mm

Stat. HS-Code

84149000
